Reliable™ RA1311 Standard Response (SR) Pendent Sprinkler | 2.8K | Brass | 155°F | Part No. F28P1BN
The Reliable™ Model F1-28 Pendent Fire Sprinkler (SIN RA1311) is a standard-response, standard-spray sprinkler designed for dependable, code-compliant fire protection in light and ordinary hazard applications. This configuration—Part No. F28P1BN—features a 2.8 K-factor and a 155°F (68°C) 5.0 mm glass bulb heat element, paired with a natural brass finish that’s well-suited for exposed installations where a classic metallic appearance is preferred.
When ambient temperature at the sprinkler reaches its rated operating point, the glass bulb activates, releasing the seal and producing a uniform standard spray pattern to help control fire growth and support system performance. The RA1311 installs with a 1/2" NPT connection (ISO 7-R1/2 optional) and is rated for a maximum working pressure of 175 psi (12 bar).
Listings and approvals
-
cULus Listed
Key specifications
-
Model: Reliable F1-28
-
Part number: F28P1BN
-
SIN: RA1311
-
Type: Pendent
-
Response / Spray: Standard Response / Standard Spray
-
K-Factor: 2.8 (40 metric)
-
Temperature rating: 155°F (68°C), 5.0 mm glass bulb
-
Thread connection: 1/2" NPT (ISO 7-R1/2 optional)
-
Max working pressure: 175 psi (12 bar)
-
Finish (this SKU): Brass
Finishes and temperature options
Available in Brass, Chrome, and White finishes with temperature ratings of 155°F, 175°F, 200°F, and 286°F.
Accessories and care
Use the correct sprinkler wrench during installation to prevent damage and ensure proper fit. Avoid over-tightening, impact, or contamination of the sprinkler and glass bulb. Do not install any sprinkler that appears damaged, painted (non-factory), or compromised. Store sprinklers in a clean, dry environment and maintain systems in accordance with NFPA 25 and AHJ requirements.
